007e High-Efficiency Circulator Pump w/ IFC, 120V
Brand: Taco
Part#: 007E-2F2
In Stock
Ship Pickup
Estimate delivery
Usually ships: within 1 business day
Pick Up available
$202.95 / each
$787.80 box of 4
($196.95 each)
Free Shipping on any qty
Add to Cart

Description

Taco 007E-2F2 is a wet rotor circulator pump with a high-efficiency ECM permanent magnet motor. The 007E is everything you love about the 007 Series circulator pump. It is ideal for hydronic systems zoned with circulators or zone valves. The 007E delivers the performance equivalent to the 007 Series circulator pumps plus the reliability and ease of installation that made the Taco 00 Series circulators famous.

Features:
  • ECM performance equivalent to the legendary 007 circulator
  • High-efficient ECM motor uses up to 85% less electricity
  • Ideal for hydronic systems zoned with circulators or zone valves
  • Bio Barrier protects pump from system contaminants
  • SureStart automatically frees locked rotor condition and self purges air from pump.
  • Integral Flow Check (IFC) included
  • Dual electrical knockouts, 6" stranded wire leads uncluded for easy wiring
  • Use with a Taco ZVC Zone Valve Control or SR Switching Relay for ON/OFF operation
  • 10' Shut-off head, 16 gpm max flow
  • Double insulated (no ground wire required)
  • Whisper quiet operation.

Technical Specifications:
  • Horsepower: 1 HP
  • Maximum Shut-off Head: 10 ft
  • Maximum Flow: 16 GPM
  • Maximum Operating Pressure: 125 psi (8.6 bar)
  • Fluid Temperature: 36-230°F (2-110°C)
  • Voltage: 120V
  • Frequency: 60 Hz
  • Motor: Single Phase
  • Maximum Operating Power: 44 Watts
  • Amperage: 0.54 A
  • Frequency of Rotation: 4830 RPM
  • Casing: Cast Iron
  • Fluids: Water or 50% Water/Glycol Solution
  • Connection Sizes: 3/4", 1", 1-1/4", 1-1/2" Flanged.

Documents

Write a Review
Helpful? Yes No
Verified Purchase
Great pump
By Kenneth (from Lakeville, MN) on 12/23/2024
Helpful? Yes No
Verified Purchase
Okay
Good
By Christopher (from Masontown, WV) on 03/30/2021

FAQs (4)

Ask a Question
Is the pump variable speed? If so, how does it vari it's speeds?
Helpful? Yes 4 No
It is not a variable speed circulator, but simply an energy-efficient version of the 007-F5 series which uses up to 85% less electricity.
By PexUniverse Customer Service on 10/06/2016
007E-F2 was discontinued Oct-28, 2018, is this still 007E-F2 stock or do you have the new 007FE-2F2 stock ?
Helpful? Yes 3 No
Our inventory is new 007e-2F2 model.
By PexUniverse Customer Service on 11/14/2018
Will this work with raddiant heat in concrete, 1600 sq ft garage?
Helpful? Yes No
To size a circulator pump, you would need to calculate flow and pressure drop in the system. Based on the limited information provided, 007 might not be enough to handle the pressure drop if you're using 1/2" PEX, but should be sufficient for 3/4" PEX (provided, of course, that it's multiple loops, not a single pipe run).
By PexUniverse Customer Service on 03/12/2024
Does the pump come with the mating flanges and for what size pipe?
Helpful? Yes No
The pump does not include flanges. Flange connection on most standard circulator pumps (Taco, Grundfos, Armstrong, Wilo, etc.) is standard, which means flanges are interchangeable.You can find them here and here.
By PexUniverse Customer Service on 10/09/2020
