The 006e3 ECM High-Efficiency Hot Water Circulation Pump
Brand: Taco
Part#: 006E3
In Stock
Ship Pickup
Estimate delivery
Usually ships: within 1 business day
Pick Up available
$325.95 / each
Free Shipping on any qty
Add to Cart

Description

NOTE: 1" NPT Union Connection w/ optional 1/2" & 3/4" fitting sold separately NOTE: Not suitable for chilled water

Cross-References:
  • Taco 003 & 006
  • Grundfos UP15-18, UP 15-10, UP 10-16
  • Armstrong Astro 225BS, Astro 225SSU, Astro 220SSU
  • and many others

Features:
  • 3 Speed settings - low, medium and high (003 and 006 performance point references)
  • High-efficiency ECM motor uses up to 85% less electricity
  • SureStart feature allows the pump run dry during air purge
  • Double insulated - no ground wire required
  • LED mode indicator for easy diagnostics
  • Equipped with a composite casing
  • Acceptable for use with water or maximum of 50% water/glycol solution in closed hydronic systems
  • cUL Listed; NSF 61 & 372 Certified

Technical Specifications:
  • Circulator Pump Type: 3-Speed
  • Material: Composite
  • Connection: 1" Union
  • Electrical: 120V, 60 Hz, 1-Phase
  • Max. Shut-Off Head: 13 ft
  • Max. Flow: 11 GPM
  • Max Operating Pressure: 150 PSI
  • Min/Max Water Temp: 36° F / 203° F
  • Max Operating Power: 44W
  • Max Amp Draw: 0.54A

Documents

Write a Review
Helpful? Yes No
Verified Purchase
Great Taco
Great energy saving hot water recirculating pump. Especially when used with the Taco Smart plug control. Have several in operation for a few years no issues .
By Joseph (from Glenwood springs, CO) on 09/23/2023

FAQs (3)

Ask a Question
Does this come with the 1 inch unions.?
Helpful? Yes 3 No
No, the unions are sold separately.
By PexUniverse Customer Service on 10/22/2019
How about a link to the appropriate unions??
Helpful? Yes 2 No
Taco Unions: UFS-050S (1/2" sweat), UFS-075T (3/4" threaded), UFS-075S (3/4" sweat). All of these and more can be found here: https://www.pexuniverse.com/circulator-pump-flanges
By PexUniverse Customer Service on 12/22/2021
Does this pump have an internal check valve?
Helpful? Yes No
No, it does not. Taco circulators with in integral check valve commonly have "IFC" in the model/part# (such as 007-F5-7IFC).
By PexUniverse Customer Service on 04/05/2024
