6-port Copper Manifold with 1/2" PEX Valves, 3/4" PEX x Closed Sioux Chief
6-port Copper Manifold with 1/2" PEX Valves, 3/4" PEX x Closed Sioux Chief
6-port Copper Manifold with 1/2" PEX Valves, 3/4" PEX x Closed Sioux Chief
6-port Copper Manifold with 1/2" PEX Valves, 3/4" PEX x Closed Sioux Chief
6-port Copper Manifold with 1/2" PEX Valves, 3/4" PEX x Closed Sioux Chief
6-port Copper Manifold with 1/2" PEX Valves, 3/4" PEX x Closed
Brand: Sioux Chief
Part#: 672XV0690
made in usa
In Stock
Ship Pickup
Estimate delivery
Usually ships: within 1 business day
Pick Up available
$98.95 / each
$949.50 box of 10 + Free Shipping
($94.95 each)
Add to Cart
Orders over $99 ship free

Description

Lead-free PEX copper manifold by Sioux Chief with crimp style, 1/4-turn shut-off PEX brass ball valves.


Features:
  • Lead-free
  • Trunk made from type L copper
  • Shut-off valves made from lead-free brass
  • Compatible with crimp ring or cinch clamp PEX connection systems
  • cUPC listed
  • Made in the USA

Technical Specifications:
  • Trunk inlet: 3/4" PEX, crimp-style
  • Trunk outlet: spin closed
  • Trunk size (diameter): 1" copper pipe (CTS)
  • Branches: 1/2" PEX (1/4-turn ball valves)
  • Number of branches: 6
  • Branch spacing: 2" OC (On Center)
  • Overall manifold size (L x H): 15-1/4" x 4.5"

Documents

Write a Review
Helpful? Yes 3 No
Verified Purchase
Manifold
Not bad but the shut off handles were much sturdier in the past. They are not the same ones pictured.
Branches: 5
By Chris (from Hackensack, NJ) on 06/28/2019
Helpful? Yes 1 No
Verified Purchase
Great Product, Great Price
I was very impressed with the quality of this product, the great price and the speed with which it was shipped. Thank you for your great service.
Branches: 4
By Edward (from Islesboro, ME) on 08/09/2019
Helpful? Yes 1 No
Verified Purchase
Manifolds
Working perfectly
Branches: 6
By Lenny (from Stanford, ME) on 04/02/2019
Helpful? Yes 1 No
Works great
Well made and easy to install. Having a copper manifold with the valves attached was a big time saver. Wish I could buy them with more than 6 outlets. I highly recommend for a house retro fit.
Branches: 4
By Weekend warrior (from Northern NJ) on 05/08/2016
Helpful? Yes 1 No
Verified Purchase
Worked Great
Great product, easy install with PEX crimp. Had no problems fitting the crimper tool between the shutoff valves. No leaks, everything seems to be good quality. I like the ability of shutting off single fixtures or areas of the house.
Branches: 4
By BR (from Virginia) on 09/10/2015
Helpful? Yes 1 No
Verified Purchase
4-port Copper Manifold, 1/2" PEX
Excellent quality, made running the lines to different sections a breeze. Its nice to be able to isolate individual drops when needed.
Branches: 4
By David W. (from Port Neches, Texas) on 03/11/2014
Helpful? Yes 1 No
so easy to use and install
One of the best products I used to isolate each faucet.
Branches: 6
By doityourselfer (from hopkinton,ny) on 04/08/2011
Helpful? Yes No
Verified Purchase
5star
awesome company
Branches: 5
By john (from Santa cruz, CA) on 04/15/2024
Helpful? Yes No
Verified Purchase
Exactly what I needed.
On time delivery. I ran 3/4 inch PowerPex to the manifolds. The valves work very nicely. Pressure tested at 100 psi which held for over 24 hours. I recommend.
Branches: 6
By Julius (from West lafayette, IN) on 10/30/2022
Helpful? Yes No
Verified Purchase
Pex manifold
Works great
Branches: 6
By Matt (from Superior, NE) on 07/09/2022
Helpful? Yes No
Verified Purchase
It was OK
Thanks for the quick service. I appreciate the speed.
Branches: 5
By Stacy (from Hayward, WI) on 03/11/2022
Helpful? Yes No
Verified Purchase
great manifold
Seems to be well built, compact & valves easy to operate. Easy & fast connecting also
Branches: 4
By Rich (from Bullhead, AZ) on 10/21/2021
Helpful? Yes No
Verified Purchase
I like it.
Its perfect.
Branches: 4
By Dervin (from Joplin, MO) on 02/20/2021
Helpful? Yes No
Verified Purchase
Good quality, fair price and excellent service.
Needed these quickly for a job. PEX Universe shipped same day and items arrived early. Excellent service!!!
Branches: 4
By John (from Nashville, TN) on 10/13/2020
Helpful? Yes No
Verified Purchase
solid, high quality
Installed two of the 4-port manifolds yesterday. They look to be high quality which is important with something you intend to use for many years. The pex fittings were accurate and no leaks.
Branches: 4
By mulqueen, (from Monte vista, CO) on 06/23/2020
Helpful? Yes No
Verified Purchase
Options
Wish you could pick which side the valves come off of depends on which side your feed line is coming from.
Branches: 4
By Philip (from Georgetown, IN) on 03/20/2020
Helpful? Yes No
Verified Purchase
Everything I needed
Needed something to replace the broken manobloc. This was everything I was hoping for.
Branches: 5
By Brodie (from Steubenville, OH) on 08/21/2019
Helpful? Yes No
Verified Purchase
Very sturdy construction.
I was not sure what to expect when I ordered these. My local stores do not carry this style of manifold (with the built in valves). They appear quite well made and sturdy. Pressured up the manifold(s) with no leaks, valves all work as expected. I used three of these, it would have been nice to have them in left and right closed end options.
Branches: 4
By Verified Buyer (from Oregon) on 01/29/2016
Helpful? Yes No
Verified Purchase
Did the job!
Nice product. Worked as you would expect!
Branches: 4
By Cabin builder (from Southern Oh) on 10/13/2015
Helpful? Yes No
Verified Purchase
Extremely well made from high quality materials
I bought two of these for our cabin, one for hot water and the other for cold. My contractor was highly impressed with them and it is a breeze to install.
Branches: 5
By Verified Buyer on 09/27/2015
Helpful? Yes No
Verified Purchase
Worked Great
Great product, easy install with PEX crimp. Had no problems fitting the crimper tool between the shutoff valves. No leaks, everything seems to be good quality.
Branches: 5
By BR (from Virginia) on 09/10/2015
Helpful? Yes No
Verified Purchase
works great
great product
Branches: 6
By Verified Buyer on 05/30/2015
Helpful? Yes No
Verified Purchase
Great Product
Worked well the first time. Solid Valves. No complaints.
Branches: 4
By Verified Buyer on 05/21/2015
Helpful? Yes No
Verified Purchase
Very Satisfied
I was surprised at how solidly constructed this unit is. It works perfectly-the valves provide a solid shut off and good flow through
Branches: 4
By Thomas H. (from Indianapolis, IN) on 05/06/2014
Helpful? Yes No
fully satisfy.
A lot shepper than canada
Branches: 5
By Bitt (from NB Canada) on 06/21/2011
Helpful? Yes -1 No
Verified Purchase
you want way to much personal info
never again will I shop here felt like ID theft on steroids
Branches: 4
By shirley (from Glenshaw, PA) on 08/21/2020

FAQs (5)

Ask a Question
Can these manifolds be used with expander type connections (Wirsbo)?
Helpful? Yes 1 No
We do stock the expansion style manifolds - click here to see them. As for your question, the answer is no. Crimp style manifolds can be used with crimp or cinch (clamp) PEX connection systems only. They are, however, compatible with all tubing types (including Wirsbo/Uponor), but you would have to use the crimp method instead of expansion method to connect the pipe.
By PexUniverse Customer Service on 10/26/2017
Can I spin the valves so that I can put the inlet on the right side? As shown, it on the left.
Helpful? Yes 1 No
The valves are soldered in place and therefore cannot be rotated. If you want the inlet to be on the right, you can get 672XV0699 model, then cut off the 3/4" PEX inlet on the left hand side and solder a 1" copper cap (part# P-5) over the trunk end. Alternatively, you could use a standard valveless manifold (672X0690), rotate it as needed and install the PEX shut-off valves (VPP012-LF) separately.
By PexUniverse Customer Service on 11/09/2015
This is approved for potable water supply? It's totally lead free? On another site this same product number is cautioned "Not for domestic water"Please advise
Helpful? Yes 1 No
Yes, they are approved for potable water use. All of the Sioux Chief manifolds we sell - with or without valves, are lead-free compliant.
By PexUniverse Customer Service on 04/27/2015
Cans this manifold be made with 12 ports?
Helpful? Yes No
We have part# 672XV1210, which is practically the same, except the inlet connection is 1" copper sweat (female). You could solder an adapter to connect to PEX pipe if needed. Adapters can be found here: https://www.pexuniverse.com/pex-copper-fitting-adapters
By PexUniverse Customer Service on 02/06/2025
Will this valve set up work with SHARKBITE pex?
Helpful? Yes No
Yes, this Sioux Chief PEX manifold model will work with any regular (US Standard SDR-9 size) PEX tubing, including Sharkbite PEX.
By PexUniverse Customer Service on 04/08/2013
