Automatic Sump Pump w/ Piggyback Wide Angle Float Switch, 10' cord, 1/3 HP, 115V Liberty Pumps
Automatic Sump Pump w/ Piggyback Wide Angle Float Switch, 10' cord, 1/3 HP, 115V
Brand: Liberty Pumps
Part#: 233
This product has been discontinued. No direct replacement is available at this time.

Description

Liberty Pump 233 is 1/3HP Automatic/Manual Submersible Sump Pump with 10ft power cord. It comes factory-equipped with a wide-angle float switch (mercury-free) mounted to the pump. This pump has two cords - one to the float switch and the other to the pump motor. The switch cord has a series (piggyback) plug enabling the pump (motor) cord to be plugged into the back of it (see attached files for details). The purpose of this design is to allow temporary manual operation of the pump if desired.

This Energy Saving Liberty Pump features deep finned powder coated aluminum motor housing that provides 225% more cooling capacity than cast iron housings. Efficient motor design reduces electrical usage by up to 40%.

The Liberty Pump 233 has 1-1/2" NPT discharge, 3/8" solids-handling, 21' max. lift. and thermally protected & permanently lubricated motor.


Features:
  • Vortex style impeller permits passage of solids without clogging. Made of high temp engineered thermoplastic
  • Polypropylene and powder coated aluminum construction
  • Stainless steel rotor shaft
  • All fasteners - non-corrosive stainless steel
  • Oil-filled, hermetically sealed motors with thermal overload protection
  • Permanently lubricated upper and lower bearings
  • Quick-disconnect 10' standard power cord allows replacement of cord in seconds without breaking seals to motor
  • Removable base allows suction down to 1/8"

Technical Specifications:
  • Horsepower: 1/3 HP
  • Cord length: 10'
  • Discharge: 1-1/2"
  • Solids Handling: up to 3/8"
  • Voltage: 115V
  • Amps: 5.2
  • RPM: 3450
  • Hertz: 60 Hz
  • Maximum fluid temperature: 140°F
  • Maximum lift: 21'
  • Height: 10.5"
  • Width: 9.6"
  • Weight: 11 lbs.
  • Minimum Sump Diameter: 14"

Warranty:
3 years manufacturer's warranty
