Laars Mascot FT 157,000 BTU Condensing Gas Combi Boiler Laars
Laars Mascot FT 157,000 BTU Condensing Gas Combi Boiler
Brand: Laars
Part#: MFTCW199NA2XN
In Stock
Pick Up ready by {{ pickupBy }}
Usually ready: within 1 hour

Description

Rebate:
This boiler meets the requirements for a federal tax credit and qualifies for a 30% (up to $600) rebate. Click here for more info.

Laars MFTCW199 model is Mascot FT series, Energy Star listed mod-con combi boiler (heat + DHW) with 157K BTU Net AHRI output.

Features:
  • 2-in-1 Combi Boiler with Space-Heating & DHW (Domestic Hot Water) functionality
  • Advanced stainless steel fire tube heat exchanger
  • Energy Star listed
  • Compatible with PVC, CPVC, PolyPropylene and St. Steel vent pipe
  • Modulating Gas Valve: easily convertible from natural gas to propane
  • Dual stage anti-freezing mechanism
  • Built-in gas leak detection with alarm

Technical Specifications:
  • Input, Max Fire (BTU): 199,000
  • Net AHRI Rating (BTU): 157,000
  • AHRI Cert. Heating Capacity (BTU): 181,000
  • Output, Max Fire (MBH): 189,050
  • Efficiency (AFUE): Up to 95%
  • Turndown (Modulation) Ratio: 10.0 : 1
  • Fuel Type: Natural Gas (NG) or Propane (LP)
  • Boiler Connections: 1" NPT
  • Gas Connection: 3/4" NPT
  • Gas Supply Pressure: 3.5 - 10.5 WC (natural gas), 8 - 13 WC (propane)
  • Boiler Pressure Relief Settings: 30 psi
  • Condensate Drain: 1/2" NPT
  • DHW Inlet / Outlet: 3/4" NPT
  • DHW Min. Flow Rate (GPM): 0.5
  • DHW Flow Rate (GPM at T° Rise): 9.8 GPM @ 35°F, 7.7 GPM @ 45°F, 4.8 GPM @ 77°F
  • DHW Pressure: 15-150 psi
  • Vent/Air Size: 3"
  • Vent Material: PVC, CPVC, PolyPropylene (recommended), St. Steel
  • Power Supply: 120V, 60Hz
  • Dimensions (Depth x Width x Height): 16.87" x 19.75" x 32"
  • Weight: 130 lbs
  • Mounting Type: Wall-mounted (Wall-hung).

Warranty:
10 Years Limited Heat Exchanger Warranty / 5 Years Parts
