FocusPRO 5000 Non-Programmable Thermostat w/ Large Display, 1H/1C Conv. or 1H/1C Heat Pump Honeywell
FocusPRO 5000 Non-Programmable Thermostat w/ Large Display, 1H/1C Conv. or 1H/1C Heat Pump
Brand: Honeywell
Part#: TH5110D1022
This product has been discontinued. No direct replacement is available at this time.

Description

Honeywell TH5110D1022 FocusPRO 5000 thermostat offers all the benefits of a digital thermostat, but without the difficulties with programming schedule. This model is designed for gas, oil or electric-powered heating systems with air conditioner or single stage (1H/1C) heat pumps with aux heat. It can also be used for heat-only or cool-only applications. FocusPRO 5000 series is packed with features, including extra-large backlit display, selectable automatic or manual changeover, easy battery change and many others.

Features:
  • Extra-large, easy to read, backlit display
  • Easy battery change (no need to remove thermostat cover) & low-battery warning
  • Selectable automatic or manual changeover
  • Displays ambient and setpoint temperature at all times
  • "Heat On", "Cool On", etc. mode on screen when operational for visual confirmation
  • Positive "Off" mode
  • 1°F temperature accuracy
  • Built-in compressor protection

Technical Specifications:
  • Programmability: Non-Programmable
  • Stages: 1 Heat / 1 Cool Conventional or 1 Heat / 1 Cool Heat Pump (Gas, oil, or electric heat with air conditioning / Warm air, hot water, high efficiency furnaces, heat pumps, steam, gravity / Heat only with fan / Cool only / 750 mV heating systems)
  • Fan Settings: Auto, On
  • Changeover: Auto or Manual
  • Interface: Soft Button
  • Display: Monochrome
  • Mounting: Horizontal
  • Color: White
  • Electrical Ratings: 24V (20-30 Vac, 0.02-0.50A or 0.02-1.00A - varies by terminal), 750mV DC
  • Power Method: Battery (AAA) or Hardwired (terminal C) with Battery Backup
  • Terminal Designations: R, Rc, C, W (O/B), Y, G
  • Dual Fuel: No
  • Setting Temperature Range: Heat 40°F - 90°F; Cool 50°F - 99°F
  • Ambient conditions: 32 to 120°F, 5 to 90% RH, non-condensing
  • Dimensions (Height x Width x Depth): 3.4" x 4.5" x 1.3"
  • Packaged Weight: 8.5 oz

Warranty:
5-year warranty
