8-Section, 5" x 20" Cast Iron Radiator, Free-Standing, Ray style
Brand: OCS
Part#: R08
In Stock
Ship Pickup
Estimate delivery
Usually ships: within 1-2 business days
$295.95 / each
$1,083.80 box of 4
($270.95 each)
Free Shipping on any qty

Cross-References:
  • Burnham (U.S. Boiler) radiator of same size
  • Governale (Gov-Ray series) radiator of same size

Technical Specifications:
  • Steam BTU: 4,320
  • BTU @ 220°F: 4,496
  • BTU @ 215°F: 4,320
  • BTU @ 210°F: 4,136
  • BTU @ 200°F: 3,776
  • BTU @ 190°F: 3,416
  • BTU @ 180°F: 3,056
  • BTU @ 170°F: 2,696
  • BTU @ 160°F: 2,336
  • BTU @ 150°F: 1,976
  • Water Content (Gal): 1.2
  • Connections: Supply/Return: 1-1/4" FNPT; Air Vent: 1/8" FNPT
  • Max Working Pressure: 15 psi (Steam), 30 psi (Water)
  • Max Working Temperature: 220°F
  • Dimensions (D x H x W): 5" x 20" x 18"
  • Weight: 112 lbs
